ÃÊÀ½ÆÄ(Surface Acoustic Wave-ÀÌÇÏ SAW)ÅÍÄ¡ ÆгÎÀº ÁÖ·Î ÀúÇ׸·¹æ½ÄÀÇ ³·Àº Åõ°úÀ²ÀÌ ¹®Á¦Á¡À¸·Î °Å·ÐµÇ¸é¼, ³ôÀº ¼öÁØÀÇ °¡½Ã¼º È®º¸Çϱâ À§Çؼ °³¹ßµÇ¾ú½À´Ï´Ù. µ¶¸³ÀûÀÎ LCD ¸ð´ÏÅͺÎÅÍ POSÅ͹̳Î, ATM, Å°¿À½ºÅ©¿Í °°Àº °ø°øÀå¼Ò¿ëÀ¸·Î ³Î¸® »ç¿ëµË´Ï´Ù. :::::::::::::::::::::::::::::::::::::::::::::::::::::::: ÃÊÀ½ÆÄÅÍÄ¡ÆdzÚÀÇ ¿ø¸®¿Í ÀÌÇØ ´õº¸±â |
TECHNICAL SPECIFICATION
Technology
|
Surface
Acoustic Wave
|
Size
|
Refer the
dimension
|
Resolution
|
4096X4096, Z
axis 256, irrelevant with the size of the touch panel
|
Material
|
Pure glass
|
Light Transmission
|
90~92%
|
Accuracy
|
<2mm (0.080
inch)
|
Durability
|
Scratch-free ;
More than 50,000,000 touches in one location without failure.
|
Touch Medium
|
Finger, Gloved
finger, Rubber soft pen etc.
|
Surface Hardness
|
Mohs¡¯ hardness
rating of 7
|
Operating Temperature
|
-20 to +60¡É
|
Storage Temperature
|
-40 to +70¡É
|
Humidity
|
10~90% 40¡É
|
Operating Altitude
|
3800m
|
Anti-chemical
properties
|
The active
area can resistant to all chemicals what do not affect glass.
Such as : Acetone, Toluene, Methyl ethyl ketone, Isopropyl
alcohol, Methyl alcohol, Ethyl acetate, Ammonia-based glass cleaners,
Gasoline, Kerosene, Vinegar.
|
Agency Approval
|
UL, CE, FCC,
RoHS, CB
|
TOUCH CONTROLLER
Size(PCB)
|
85X55X10(mm)
|
Interface
|
USB and RS232C
|
Working Voltage
|
5V
|
Working current
|
USB : 70mA,
RS232C : 120mA
|
Maximum current
|
USB : 80mA,
RS232C : 130mA
|
Resolution
|
4096X4096, Z
axis 256, irrelevant with the size of the touch panel
|
Response Time
|
¡Â10ms
|
Operating Temperature
|
-20 to +70¡É
|
Operating Humidity
|
10~90%RH
|
Storage Temperature
|
-40 to +85¡É
|
Multi-point Touch
|
Intelligent
discrimination by software
|
Touch Activation Force
|
40g
|
MTBF
|
25,000 hour
|
Driver Available
|
Windows 2000,
Windows XP, VISTA, 7, 10, Windows NT, MAC, Linux
|
Agency Approval
|
UL, CE, FCC,
RoHS, CB
|
PANEL LIST (EXAMPLE)
SIZE
|
MODEL
|
OUTLINE
|
VIEWABLE AREA
|
ACTIVE AREA
|
15"
|
KAL-0151-6BS
|
348*277
|
314*239
|
306*230
|
17"
|
M-WVT-170N-4F
|
362*299
|
341*274
|
338*271
|
22"
|
M-WVT-220C-4K
|
511.5*338
|
479.5*302
|
475.5*297
|
24"
|
KAL-0240-4B-AL
|
554*361
|
523*329
|
520*326
|
¸®½ºÆ® »óÀÇ »çÀÌÁî ¿Ü¿¡µµ 10.4ÀÎÄ¡ºÎÅÍ ´Ù¾çÇÑ »çÀÌÁî·Î Á¦°ø °¡´ÉÇÏ¿À´Ï º°µµ ¹®ÀÌ ¹Ù¶ø´Ï´Ù.
