- Lightweight foil simple to apply to a window,
glass, acrylic and rear projection screens
- No requirement to have any external wires or
devices as all of the touch screen components are situated safely behind
the
glass
- Interactivity works even with gloved
hand
- Not affected by external light
conditions
- Wide range of screen sizes available up to 100¡±
4:3 or 16:9 format
- Works with all existing multimedia applications
PowerPoint, Macromedia flash, Web sites etc.
- Simple set-up
- Detection Method: Projected Capacitance
technology using horizontal vertical wires
- Screen Sizes: 40¡±- 84¡± 4:3 32¡±-180¡±16:9 as
standard, other sizes available on request
- Fixing options: Removable and permanent options
available
- Position accuracy: Approximately 3 mm absolute,
1 mm relative. No drift
- Alignment: Software drivers provide a
calibration facility
- Sensitivity: Can be programmed for different
thickness of glass and even use with gloved hands. Standard configuration
functions with non-metallised. single construction glass 16mm thick. Double
glazing option up to 25mm available*
- Speed of response: Depends upon glass
thickness. Typically 50 to 100ms
- Output: USB or RS232.
- Software Compatibility: Drivers are available
for Windows Operating Systems
- Temperature range: Better than -10 to
+70°C
- Humidity Controller: 0% to 95%. Unaffected by
condensation
- Light Transmission: Typically better than
93%.
- EMC: EN55022:1998 + A1 + A2 EN55024:1998 + A1 +
A2
* Double glazing option In this mode we recommend only
touch not the touch and drag function. The drag functionality is limited due to
the reduction of the scan rate to achieve the touch function through thicker
materials Due to the variation in double construction glass we recommend testing
with a foil during the survey of each individual site since it is impossible to
guarantee the foil will function in all cases
|
