FINDUS - PANEL MOUNT TOUOCH MONITOR 10.4" 12.1" FOR INDUSTRIAL

FI104P Suffix-C

- Display : 10.4 inch

- Resolutin : 800 X 600 (SVGA/60Hz)

- Brightness / Contrast : 350 nit / 800

- Power input : DC12V

- Outline dimension(W X H X D mm) : 270.0 X 214.0 X 49.3

The Rear cover size for reference.

- Dimension(W_R X H_R mm) : 243.0 X 187.0

General Outline Dimension

Model	Video Input	Type of Touch Screen	Type of Touch Controller	Remarks
FI104PN-D-C11	VGA / DVI (HDMI)	N	N
FI104PT-D-C11	VGA / DVI (HDMI)	Resistive	USB
FI104PT-D-C12	VGA / DVI (HDMI)	PCAP	USB	10 Points

Reverseable Screen

Wide View Angle

High Brightness

FI104P Suffix-X

- Display : 10.4 inch

- Resolutin : 1024 X 768 (XGA/60Hz)

- Brightness / Contrast : 400 nit / 1400

- Power input : DC12V

- Outline dimension(W X H X D mm) : 270.0 X 214.0 X 49.3

The Rear cover size for reference.

- Dimension(W_R X H_R mm) : 243.0 X 187.0

General Outline Dimension

Model	Video Input	Type of Touch Screen	Type of Touch Controller	Remarks
FI104PN-D-X01	VGA / DVI (HDMI)	N	N	VA
FI104PN-D-X11	VGA / DVI (HDMI)	N	N	TN
FI104PT-D-X01	VGA / DVI (HDMI)	Resistive	USB	VA
FI104PT-D-X11	VGA / DVI (HDMI)	Resistive	USB	TN
FI104PT-D-X02	VGA / DVI (HDMI)	PCAP	USB	2 Points /VA
FI104PT-D-X12	VGA / DVI (HDMI)	PCAP	USB	10 Points / TN

Reverseable Screen

High Brightness

Vandal proof

with 6mm tempered

SAW touch screen

- Optional

FI121P Suffix-C

- Display : 12.1 inch

- Resolutin : 800 X 600 (SVGA/60Hz)

- Brightness / Contrast : 400 nit / 500

- Power input : DC12V

- Outline dimension(W X H X D mm) : 330.0 X 264.5 X 56.2

The Rear cover size for reference.

- Dimension(W_R X H_R mm) : 298.0 X 234.5

General Outline Dimension

Model	Video Input	Type of Touch Screen	Type of Touch Controller	Remarks
FI121PN-D-C01	VGA / DVI (HDMI)	N	N
FI121PN-A-C01	VGA / CVBS / HDMI	N	N
FI121PT-D-C01	VGA / DVI (HDMI)	Resistive	USB
FI121PT-D-C03	VGA / DVI (HDMI)	SAW	USB&RS232C

Reverseable Screen

High Brightness

Vandal proof

with 6mm tempered

SAW touch screen

- Optional

F121P Suffix-X

- Display : 12.1 inch

- Resolutin : 1024 X 768 (XGA/60Hz)

- Brightness / Contrast : 500 nit / 700

- Power input : DC12V

- Outline dimension(W X H X D mm) : 330.0 X 264.5 X 56.2

The Rear cover size for reference.

- Dimension(W_R X H_R mm) : 298.0 X 234.5

General Outline Dimension

Model	Video Input	Type of Touch Screen	Type of Touch Controller	Remarks
FI121PN-D-X01	VGA / DVI (HDMI)	N	N
FI121PN-A-X01	VGA / CVBS / HDMI	N	N
FI121PT-D-X01	VGA / DVI (HDMI)	Resistive	USB
FI121PT-D-X03	VGA / DVI (HDMI)	SAW	USB&RS232C

* If you would like more details, just click here
