Out-Line Dimension
106.8 X 51.5 X 15.5(MAX)
|
|
Video Input
|
PC-RGB
|
Format
|
Up to
1920X1080(60Hz)
|
|
Color
|
16bit, 24bit,
32bit
|
|
DVI
|
Format
|
Up to
1920X1080(60Hz)
|
|
Operating speed
|
165MHz
|
|
Audio Input
|
PC-RGB
|
PC : Ear phone input
|
|
Power
|
Power
Requirement
|
12V
|
|
To panel
|
3.3V,5V,12V
|
|
Manage
|
Low power consumable mode:
standby<3w
|
|
OSD Language
|
Chinese, English, French ,
Italian, German, Korean, Russian, Spanish(Option )
|
|
Key Functions
|
Select/Exit, Menu, Auto, Left,
Right
|
|
Audio
|
Output 2*2w (8 )
|
|
Panel Resolutions
|
Up to 1920X1080@60HZ
|
|
I/O Layout
|
Input
|
PC-RGB Input
|
1D-SUB 15PIN
terminal blue color
|
|
PC-RGB Audio Input
|
1 earphone
terminal black color
|
|
DVI input
|
1 DVI 24PIN
|
|
Output
|
To Panel
|
LVDS 30PIN/2.0
jack
|
|
