MARKET
AREA
|
North
America Market.
|
|
OSD
LANGUAGE
|
(English,
Chinese, French, Spanish, Portuguese,Russian,Turkish)
|
|
CHIPSET
|
RTD2841ASM
|
|
POWER
|
AC
Input Requiremen
|
AC90～264V
50/60HZ
|
|
To
Panel
|
5V/12V
|
|
Management
|
Low
power consumable mode: standby≤0.5W
|
|
VIDEO
INPUT
|
ATV
|
VIDEO
SYSTEM
|
PAL/NTSC
|
|
SOUND
SYSTEM
|
MN
|
|
RECEIVE
CHANNEL
|
ATV:200
|
|
ATSC
|
MODULATION
|
Air:8-VSB;Cable:64QAM,256QAM
|
|
VIDEO
SYSTEM
|
MPEG-2
MP@ML
|
|
AUDIO
SYSTEM
|
AC-3,MPEG1/2
LayerⅠand Ⅱ
|
|
RECEIVE
CHANNEL
|
Air:2-69;Cable:1-135
|
|
CVBS
|
1.0Vp-p
+/-5%
|
|
YPbPr/YCbCr
|
480i、480p、576i、576p、720p、1080i、1080p
|
|
PC-RGB
|
Format
|
Up
to 1920*1080@60HZ
|
|
HDMI
|
480i、480p、576i、576p、720p、1080i、1080p
|
|
AUDIO
INPUT
|
Audio
System
|
DD/DD+(Option
& need license)
|
|
AV
Audio Input
|
2
RCA terminal white color，red
color
|
|
EXPANSION
FUNCTION
|
USB/HDMI
|
YES
|
|
PANEL
RESOLUTIONS
|
1920*1080
|
|
KEY
FUNCTIONS
|
C-,C+,M,V-,V+,
S, EN
|
|
AUDIO
OUTPUT
|
2*5W@8Ω
|
|
COMB
FILTER
|
3D
|
|
DE-INTERLACE
|
3D
|
|
WEAK
SIGNAL ENHANCEMENT
|
YES
|
|
NOISE
REDUCTION
|
3D
|
|
EPG
|
YES
|
|
Terminal
(input)
|
TV
|
1×
F type 75 Ω for ATSC
|
|
HDMI
|
2×HDMI
terminal,HDMI 1 with ARC
|
|
USB
|
2×USB2.0
|
|
PC-RGB
|
1
D-USB 15PIN terminal,blue color
|
|
AV
|
RCA
terminal ,yellow white red color
|
|
MINI
AV
|
Mini@3.5MM
black type socket
|
|
YPbPr
|
Mini@3.5MM
black type socket
|
|
RJ45
|
1
RJ45 terminal
|
|
Terminal
(output)
|
To
Panel
|
30PIN
LVDS
|
|
SPDIF
|
Optical
fiber or Coaxial terminal
|
|
Earphone
|
1
Earphone terminal black color
|
USB
multimedia playback format
|
1.
Video Decoder Support List
|
|
Type
|
Video
Decoder
|
Resolution
|
Max
fps
|
Max
bitrate
(
Mbps )
|
Bit
depth
|
Support
|
|
MPEG
1/2/4
|
MPEG1
|
1920x1080
|
60
|
50M
|
8
|
√
|
|
MPEG2
MP@HL
|
1920x1080
|
60
|
50M
|
8
|
√
|
|
MPEG-4
SP@HL 3.0
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
MPEG-4
ASP@HL 4.0
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
MPEG-4
version3 (MP43)
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
Microsoft
ISO MPEG-4
version
1 (MP4S)
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
Microsoft
ISO MPEG-4
version
1.1 (M4S2)
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
Xvid
|
XviD
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
H.264
|
H.264
BP LV 4.0
|
1920x1080
|
60
|
125M
|
8
|
√
|
|
H.264
MP LV 4.0
|
1920x1080
|
60
|
125M
|
8
|
√
|
|
H.264
HP LV 4.0
|
1920x1080
|
60
|
125M
|
8
|
√
|
|
H.264
MP LV 5.1
|
1920x1080
|
30
|
125M
|
8
|
√
|
|
H.264
HP LV 5.1
|
1920x1080
|
30
|
125M
|
8
|
√
|
|
H.264
MVC (version 11)
|
1920x1080
|
30
|
150M
|
8
|
√
|
|
H.265
|
H.265
Main profile@Level 4.1
|
2048x1080
|
60
|
125M
|
8
|
√
|
|
H.265
Main10 profile @Level 4.1
|
2048x1080
|
60
|
125M
|
8/9/10
|
√
|
|
H.265
Main profile@Level 5.0
|
2048x1080
|
30
|
125M
|
8
|
√
|
|
H.265
Main10 profile @Level 5.0
|
2048x1080
|
30
|
125M
|
8/9/10
|
√
|
|
H.265
Main profile@ Level 5.1
|
2048x1080
|
60
|
150M
|
8
|
√
|
|
H.265
Main10 profile @Level 5.1
|
2048x1080
|
60
|
150M
|
8/9/10
|
√
|
|
H.265
Still picture profile
|
8192x4096
|
NA
|
NA
|
8
|
√
|
|
Generic
|
Motion
JPEG
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
SHVC
|
NA
|
1920x1080
|
60
|
150M
|
8/9/10
|
√
|
|
WMV
|
Window
Media Video v9
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
VC1
|
VC-1
(SP/MP/AP)
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
VP8
|
VP8
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
VP9
|
VP9
|
4096x2160
|
60
|
150M
|
8/10
|
√
|
|
AVS
|
AVS
Jizhun Profile LV 6.0
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
AVS
Plus
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
Sorenson
|
Sorenson
H.263
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
Motion
JPEG
|
M-JPEG
|
1920x1080
|
60
|
25M
|
8
|
√
|
|
H.263
|
H.263
V_MS/FW/FOURCC/ H263
|
1920x1080
|
30
|
25M
|
8
|
√
|
|
2.
Audio Decoder list
|
|
PN
|
Audio
Decoder (For MM Video)
|
Support
|
|
PCM
|
wav:
PCM / ADPCM / A-law PCM / u-law PCM
|
Yes
|
|
ADPCM
IMA4
|
Yes
|
|
WAV(192KHz)
|
Yes
|
|
AMR
|
AMR-NB,
AMR-WB/AMR-WB+
|
Yes
|
|
LPCM
|
DVD
LPCM
|
Yes
|
|
MPEG
1/2/4
|
MPEG1
Layer1/2
|
Yes
|
|
MPEG1
Layer1/2 (MPEG2)
|
Yes
|
|
MP3
(MPEG1 Layer3)
|
Yes
|
|
MPEG-H
3D Audio
|
Yes
|
|
AAC
|
MPEG2
AAC (AAC-LC)
|
Yes
|
|
MPEG4
AAC-LC
|
Yes
|
|
MPEG4
HE-AAC v1/v2
|
Yes
|
|
raac:
MPEG4 AAC-LC (RealAudio9)
|
Yes
|
|
racp:
MPEG4 HE-AAC v2 (RealAudio10)
|
Yes
|
|
Dolby
AC3 (DD)*
|
AC3
|
Yes
|
|
dnet:
AC3 (RealAudio3)
|
Yes
|
|
Dolby
EAC3
(DDCO)*
|
Dolby
Digital Plus
|
Yes
|
|
Dolby
Digital Plus, Dolby lossless
|
Yes
|
|
DRA
|
DRA
( licensee needed )
|
Yes
|
|
MPEG-H
|
MPEG-H
|
Yes
|
|
FLAC
|
FLAC
|
Yes
|
|
FLAC
(96hz)
|
Yes
|
|
VORBIS
|
VORBIS
|
Yes
|
|
3.
Image Decoder
|
|
File
Extension
|
Container
|
Data
Type
|
Support
|
|
|
JPEG
|
baseline
|
Yes
|
|
progressive
|
Yes
|
|
|
BMP
|
|
Yes
|
|
|
PNG
|
|
Yes
|
|
|
GIF
|
static
|
Yes
|
|
animation
|
Yes
|
|
.mpo
|
MPO
|
3d
|
Yes
|
|
.jps
|
JPEG
|
3d
baseline
|
Yes
|
|
.pns
|
PNG
|
3d
|
Yes
|
P50-2843V3.2
is a multi-in-one driver board, integrate power supply, LED driver
and TV board. The RF Can receive the ATV and ATSC television
signals,Chip built-in 1G or 1.5G DDR3,4G/8GMC.It can be used in
intelligent network TV and applies to the market in North
America. It
supports full HD LCD panel,support 2K HD panel decoding.
P50-2843V3.2
support RJ45 network signal, USB 2.0, HDMI 1.4, VGA, AV,PC Audio,and
analog TV, ATSC, also support WiFi access as well as
Earphone,Coaxial/Optical Fiber output.
P50-2843V3.2
based on Android 11 operating system.
The
power part of P50-2843V3.2 is an energy-efficient ultrathin switching
power supply unit, with backlight power under 25W. It fits to 26”
to 32” LED backlight TFT panel.
|
